Floor Angle Guide
A continuous run of 5″ × 3″ × 1/4″ structural angle bolted to the slab along the base of a rack row, wall or partition. Rather than guarding a single upright, it takes glancing contact along the whole length and steers the truck back into the aisle, which is what makes it useful in front of pallet flow rails and in-plant offices. Supplied in lengths up to 20 feet.
Technical Specifications
Related products
WorldGuard is a pallet rack frame protector that reinforces and protects the column at the same time. The 24″-tall, 3/16″-thick channel mounts tightly around the column with a bull-nose deflector that pushes forklifts away from the frame; it installs from the front of the rack using the manufacturer's exclusive T-bolt hardware.
- Size: 24″ tall × 3-1/2″ wide
- Thickness: 3/16″ steel
- Deflector: 3″ high × 5/16″ bull-nose
- Fit: Universally punched for all rack brands (3″ cols; 4″ avail.)
The manufacturer's most popular post protector for reach-truck applications, shielding rack uprights from forklift impacts. The 4″-high V-nose is built from 5/16″-thick steel to absorb outrigger impact and mounts above the footplate with a 3/4″-diameter floor anchor.
- Height: 4″ high (fits under low beam levels)
- Construction: 5/16″-thick steel
- Fits: 3″-wide rack columns (others available)
- Mounting: 3/4″-dia. floor anchor (sold separately)
A floor-mounted pallet rack column guard that protects the bottom portion of the frame where most outrigger and forklift damage occurs. Built from 3/16″-thick steel and available in 12″, 18″ or 24″ heights to suit different exposure levels.
- Mount: Floor-mounted
- Construction: 3/16″-thick steel
- Footplate: 6″ × 7-3/4″ with (4) 5/8″-dia. anchor holes
- Heights: 12″ · 18″ · 24″
