Forklift Wheel Stops (Curbs)

A welded U-shaped steel guard that sits in front of a machine or panel and takes the hit instead of it. Built from 5″ × 5″ × 3/16″ tube on two 9″ × 9″ × 3/8″ base plates, it bolts to the floor or sets in concrete. Three heights and two widths, painted safety yellow.

• Tube: 5″ × 5″ × 3/16″ structural steel
• Base plates: 9″ × 9″ × 3/8″, drilled for 5/8″ holes
• Sizes: 10″, 24″ or 42″ high × 36″ or 48″ wide
• Mounting: Surface-bolted or set in concrete · 1/2″ anchors (8), not included

A bolted steel industrial guard rail that protects machinery, walkways, in-plant offices, personnel and inventory from forklift damage. Four-way posts are punched on all sides to build any barrier shape, and the system is powder coated safety yellow for maximum visibility.

• Post: 4-3/4″ × 4-3/4″ × 3/16″-thick, 42″ or 18″ high
• Footplate: 10″ × 10″ × 1/2″-thick with (4) 7/8″-dia. anchor holes
• Rail: 12″ high × 1/8″-thick, double-ribbed; 2′–10′ on post centers
• Impact rating: 12,000 lbs. at 4 mph

Heavy structural-steel angle rail that bolts flat to the floor to keep forklifts and AGVs on line down aisles and guide them safely into dock approaches, past walls, and along equipment runs. All-welded gussets and radiused entry curves deflect wheel contact and shield rack ends and structural legs from over-steer. Surface-mounted on regular anchor centers with no concrete work · powder-coated safety yellow.

• Rail: 5″-tall structural steel angle (also 3″×4″ / 4″×4″)
• Material: 5/16″-thick steel · ~8.4 lb/ft
• Standard lengths: 9.5 ft and 10 ft sections, coupled for continuous runs
• Install: Floor-anchored, holes on ~24″ centers; entry guide curves
