Double Flanged Style Pallet Support
A World XBar pallet support bar, also called a pallet rack cross bar, whose double-flanged design lays on top of the rack beam — which the manufacturer says helps reduce beam spread. Drops in place for easy installation and adds support under full-pallet loads where full wire-deck coverage isn't required. The manufacturer publishes no load rating for the World XBar range, so if the bar is carrying load in your calculation, get the figure on the quote.
Technical Specifications
Related products
A flush-fit World XBar pallet support bar (cross bar) for 1-5/8″ step beams, and the most cost-effective World XBar option. The flush design keeps the beam face clear for labels, with Tek screw installation recommended.
- Style: Hat / flush fit
- Material: 16 ga. steel, four-corner roll-formed
- Fits: 1-5/8″ step beams
- Finish: Galvanized standard (optional powder coat)
A heavy-duty World XBar pallet support bar (cross bar) designed for structural-style beams, built with a 1/4″-thick welded cuff design. Drops in place for easy installation and ships standard with a durable powder coat finish.
- Style: Structural, welded cuff
- Cuff thickness: 1/4″ thick
- Material: 16 ga. steel, four-corner roll-formed
- Fits: Structural-style beams
Waterfall wire mesh decking with a flared channel, the flared end is welded to the wire for a clean, snag-free fit. Drops onto rack beams with no hardware, lets light and sprinkler water through, and far outperforms wood for strength and fire-code compliance.
- Mesh pattern: 2-1/2″ × 4″ × 6 ga.
- Mesh options: 1″ × 4″ and 2″ × 4″ also available
- Support channel: 14 or 16 ga.
- Fits: Most pallet rack beams
Let our engineers spec it.
Send a rack drawing or a photo. We'll return a per-bay layout with quantities, install notes, and a detailed quote.
