Structural Style Pallet Support

A World XBar pallet support bar, also called a pallet rack cross bar, whose double-flanged design lays on top of the rack beam — which the manufacturer says helps reduce beam spread. Drops in place for easy installation and adds support under full-pallet loads where full wire-deck coverage isn't required. The manufacturer publishes no load rating for the World XBar range, so if the bar is carrying load in your calculation, get the figure on the quote.

• Style: Double flanged, lays on top of beam
• Material: 16 ga. steel, four-corner roll-formed
• Fits: All 1-5/8″ step beams
• Finish: Galvanized standard (optional powder coat)

A flush-fit World XBar pallet support bar (cross bar) for 1-5/8″ step beams, and the most cost-effective World XBar option. The flush design keeps the beam face clear for labels, with Tek screw installation recommended.

• Style: Hat / flush fit
• Material: 16 ga. steel, four-corner roll-formed
• Fits: 1-5/8″ step beams
• Finish: Galvanized standard (optional powder coat)

Waterfall wire mesh decking with a flared channel, the flared end is welded to the wire for a clean, snag-free fit. Drops onto rack beams with no hardware, lets light and sprinkler water through, and far outperforms wood for strength and fire-code compliance.

• Mesh pattern: 2-1/2″ × 4″ × 6 ga.
• Mesh options: 1″ × 4″ and 2″ × 4″ also available
• Support channel: 14 or 16 ga.
• Fits: Most pallet rack beams
